5050

OWNERS MANUAL

Premier Series

7-Day Programmable

Single Stage Heat / Cool

Digital Thermostat

Compatible with low voltage single stage gas,

oil or electric heating or cooling systems,

including single stage heat pumps. This

thermostat can also be used on 250mv to

750mv millivolt heating only systems.

Do not use this thermostat on applications

with voltages above 30 Volts AC.

READ ALL INSTRUCTIONS BEFORE PROCEEDING

Store this

booklet for

future reference

Braeburn Systems LLC, as an Energy Star partner

has determined that this product meets the Energy

Star Guidelines developed by the U.S. Environmental

Protection Agency & the U.S. Department of Energy

for maximum energy efficiency.

WARRANTY

YEAR

LIMITED

CONTENTS

WARNING!

Quick Reference Contents Guide

Important Safety Information

FEATURES

SPECIFICATIONS

INSTALLATION

Replacing Existing Thermostat

Installing Your New Thermostat

TESTING YOUR NEW THERMOSTAT

PROGRAMMING

Default Thermostat Settings

Setting Current Time of Day and Day o f Week

Setting Temperature Differential a nd Residual

Cooling Fan Feature

Setting Temperature Differential

Setting Residual Cooling Fan Feature

Setting Your Energy Saving Programs

Tips Before Starting

Using Quick Program Groups

or Individual Day Programming

Entering Your Program

ADDITIONAL OPERATION FEATURES

Review Set Temperature

Temporary Program Override

Permanent Hold (Vacation) Mode

High Temperature Safety Switch

Low Temperature "Freeze" Protection

Compressor Protection

Changing Fahrenheit (˚F) to Celsius (˚C)

Low Battery Detection and Replacement

Replacing the Batteries

Resetting T hermostat

TROUBLESHOOTING

WIRING DIAGRAMS

5.1

3.1

3.2

5.2

5.3

5.4

6.1

6.2

6.3

6.4

6.5

6.6

6.7

6.8

6.9

5.3.1

5.3.2

5.4.1

5.4.2

5.4.3

6.8.1

• Always turn off power to the air conditioning or heating system prior to installing,

removing, cleaning or ser vicing thermostat.

• Read this manual thoroughly prior to installing, programming or operating this

thermostat.

• This thermostat is designed for use with a 24 Volt AC low voltage single stage gas

oil or electric heating or cooling system. This thermostat can also be used on

250mv to 750mv millivolt heating only systems.

• Do not use this thermostat on applications with voltages higher than 30 Volts AC.

• This thermostat requires two (2) properly installed "AA" alkaline batteries to

provide power for the thermostat to properly control the system operation.

• The system must have 24 Volt AC power present for proper system operation and

control.

• Wiring must conform to all building codes and ordinances as required by local

and national code authorities having jurisdiction.

• Do not short (or jumper) across terminals on the gas valve or at the hea ting or

cooling system control board to test the thermostat installation. This could

damage the thermostat and void the warranty.

• Do not select COOL mode of operation if the outside temperature is below 50˚ F

(10˚ C). This could possibly damage the controlled cooling system and may cause

personal injury.

• This thermostat should only be used as described in this

manual. Any other use is not recommended and will void the warranty.

1 2 3 4 5 6 7 8 9

Summary of Contents

Page 1 - OWNERS MANUAL

5050OWNERS MANUALPremier Series7-Day ProgrammableSingle Stage Heat / CoolDigital ThermostatCompatible with low voltage single stage gas,oil or electri

Page 2

FEATURESSPECIFICATIONS122• Contemporary Styling with Large LCD Display• 7 Day Programming Flexibility• Battery Powered (2 "AA" Alkaline batt

Page 3 - WARNING!

4INSTALLATION33.2Installing Your New Thermostat cont.TESTING YOURNEW THERMOSTAT4NOTE: Test your thermostat prior to programming any user settings. Pre

Page 4 - PROGRAMMING cont

6PROGRAMMING cont.55.2Setting Current Time of Day and Day of Week cont.5.3Setting Temperature Differential and ResidualCooling Fan FeatureSetting Temp

Page 5

8PROGRAMMING cont.55.4Setting Your Energy Saving Programs cont..5.4.2Using Quick Program Groups or Individual Day Programming cont..9PROGR AMMINGCONTI

Page 6 - OPERATION FEATURES

10NOTE: The installer can reset the thermostat and bypass the compressor protectionfeatures by pressing the RESET button. This will erase all entered

Page 7 - TROUBLESHOOTING

12TROUBLESHOOTING7SYMPTOM POTENTIAL SOLUTIONVerify your program setpoint time entries. The heating andcooling programs utilize the same setpoint times

Page 8 - WIRING DIAGRAMS

14SYMPTOM POTENTIAL SOLUTIONThermostat will notallow me to programa setpointtemperature higherthan 90˚ F (32˚ C).This is above the normal thermostat t

Page 9

16WIRING DIAGRAMS8cont.Rc Rh GRemoveFactory InstalledJumperTypical 5-Wire Two Transformer Heating and Cooling SystemW Y B OHeatControlFanControlCoolCo
